BEI KIMCO MAGNETICS INTRODUCES LIMITED ANGLE TORQUE MOTOR FEATURING ZERO COGGING FOR SMOOTH OPERATIO

Product News Wednesday, January 11, 2012: BEI Kimco



VISTA, Calif., – January 9, 2011 – Precision positioning and actuation applications require exceptionally smooth motor operation without disruption from cogging. To meet these highly specialized demands, BEI Kimco Magnetics, a brand of Custom Sensors & Technologies (CST), Inc., has introduced the new BLDC Limited Angle Torque Motor Model LAT40-48. The LAT40-48 Motor meets market demand for a zero cogging motor with high peak force in a small form factor package.



The LAT40-48 motor is a limited angle torque motor. The rotor of this motor has no preferred position. These design elements combine to provide a motor that completely eliminates cogging. The result is consistent, extremely smooth performance critical to applications that depend on uninterrupted operation, such as stabilization platforms, scanning and beam steering.

“The beauty of this limited angle torquer is that it has absolutely zero cogging or detent which makes it ideal for stabilization applications,” says Jim McNamara, BEI Kimco’s Senior Applications Engineer. “To have that kind of torque without cogging is quite unique to the market.”

The new motor also features a single phase winding that provides easy control - a 30 degree excursion is accomplished with no commutation. Use of rare earth, high energy magnets creates a power density of 10.08 oz-in Watt. Other important performance characteristics include +/- 15 degree stroke, a peak torque of 21.5 Nm, and single phase winding. These high level functions are all packed in a compact 100.0 mm diameter by 100.0 mm stack length size.

As a Brushless DC Motors (BLDC) with fixed magnets, the LAT40-48 offers all the inherent advantages over brushed DC motors, including more torque per weight, more torque per watt (increased efficiency), increased reliability, reduced noise, longer lifetime (no brush and commutator erosion) and overall reduction of electromagnetic interference.

“While many companies make full rotation motors and even custom full rotation motors, not many companies offer custom limited angle torque motors” explains McNamara. “When you can’t find what you’re looking for in an off-the-shelf product, BEI can provide the solution – we use state of the art materials and design processes to provide custom products to meet extreme requirements.”

BEI Kimco products have been used successfully in countless applications from high-end Industrial to Military and Aerospace to Medical applications. The ability to provide high performance solutions tailored to the specific needs of the customer has allowed BEI Kimco to fulfill many challenging requirements.

For further information contact BEI Kimco Magnetics, 1499 Poinsettia Ave., Suite 160, Vista, CA 92081, USA, Tel: (760) 597-7042; Toll-free: (800) 572-7560; Fax: (760) 597-6320; email:sales@beikimco.com

About BEI Kimco Magnetics:
BEI Kimco Magnetics is an operation of Custom Sensors & Technologies (CST). BEI Kimco Magnetics was founded in 1974 and is a leading manufacturer of high speed, fractional horsepower brushless bldc motors, voice coil actuators, smart voice coil actuators and bldc motor controllers for the Transportation, Industrial, and Aerospace & Defense markets. These products are used across a wide range of applications including medical and scientific, factory and office automation, optics, semiconductor/electronics, military, aviation, space systems, and security. Kimco merges leading-edge capabilities and cost-effective manufacturing know-how with highly customized applications expertise. About Custom Sensors & Technologies:
Custom Sensors & Technologies (CST) is a specialist in sensing, control and motion products. Through its brands, BEI Kimco, BEI Sensors, BEI PSSC, Crouzet, Crydom, Kavlico, Newall and Systron Donner, CST offers customizable, reliable and efficient components for mission-critical systems in Industrial, Aerospace & Defense, and Transportation markets. Focused on premium value offers and committed to excellence, CST, with more than 4,000 employees worldwide and sales of $530M US in 2009, is the dependable and adaptable partner for the most demanding customers. www.cstsensors.com
